– Rotational flickering function by the sequential flashing
– Long life expectancy due to the HID LED light source
– Select Ø84 round cap, direct mounting or supporter mounting
– Excellent visible rays transmissivity due to using an acryl cap
– Solid and smart design
– Degree of protection IP54
– Rotational flickering function by the sequential flashing
– Long life expectancy due to the HID LED light source
– Select Ø84 round cap, direct mounting or supporter mounting
– Excellent visible rays transmissivity due to using an acryl cap
– Solid and smart design
– Degree of protection IP54
| Model | LT-R |
LT-P |
LT-PB |
| Appearance |  |
 |
|
| Function | Rotating, Flashing | Rotating, Flashing, Buzzer | |
| Cap shape | Round type cap (Ø84) | ||
| Installation type | supporter mounting installation | direct installation | |
| Power supply voltage | 12 – 48 V d.c, 12 – 24 V a.c, 110/220 V a.c 50/60 ㎐ | ||
| Power consumption | Max 2.9 W (Power supply voltage : 12 – 48 V d.c)Max 5 W (Power supply voltage : 110 / 220 V a.c) | ||
| Sequential number of rotation | Approx 90 times / Min (flashing speed approx. 50 times / min) | ||
| Light source | LED ※ LED quantity : 24 | ||
| buzzer | – | Buzzer melody 2 kinds (single, beeping) sound pressure decibel : 80 ㏈ (1m distance) |
|
| Material | Protective cap: acryl resin, Body: ABS resin | ||
| Cap color | Red, Yellow, Green | ||
| Degree of protection | IP54 | ||
| Model | Code | Description | |||
| LT- | |
|
|
Signal light (Ø84 Cap) | |
| Installation type (Function) |
R | Supporter mounting (rotating, flashing) | |||
| P | Direct mounting (rotating, flashing) | ※ Optional supporter (STM-105) | |||
| PB | Direct mounting (rotating, flashing, buzzer built in) | ||||
| Power supply voltage |
12 | 12 – 48 V d.c, 12 – 24 V a.c 50 – 60 ㎐ | |||
| 012 | 110 / 220 V a.c 50 – 60 Hz | ||||
| Cap color | R | Red | |||
| Y | Yellow | ||||
| G | Green | ||||
