Warning Light – Hanyoung Nux WMS

Features

– 1~5 modules, suitable for wall mounting
– Long life expectancy by HID LED light source
– 2 types of buzzer melodies (single melody/beeping)
– Continuous light indication, flashing light indication
– Degree of protection IP54

Enquiry
Categories: , , ,
Love0

Features

– 1~5 modules, suitable for wall mounting
– Long life expectancy by HID LED light source
– 2 types of buzzer melodies (single melody/beeping)
– Continuous light indication, flashing light indication
– Degree of protection IP54

Specification

Model WMS-AC51 WMS-FC51
Appearance
Function Only for continuous light Continuous light, flashing light, buzzer
(selected by the external signal)
Stacking number 1 ~ 5 stack
Buzzer –
–
: PLAY :STOP
※ Please press button to listen buzzer
– 2 types of melodies (single melody/beeping)
70 ㏈ (1 m distance)
Flashing time – Approx 60 times / 1 min
Power supply voltage 24 V d.c/a.c (Dual usage), 50 – 60 ㎐
※ 12 V d.c/a.c 50 – 60 ㎐ (Order made)
Power consumption 3.2 W max (including the 5 buzzer) ※But, 0.5 W (Lamp/1 stack)
Light source LED
Material Lens : Polycarbonate (P.C), Body : ABS
Lens color Red, Yellow, Green, Blue, White (Left to right, top to button)
Degree of protection IP54

Ordering Code

Model Code Description
WMS- Wall mounted light
Function A Only for continuous light
F Continuous light, flashing light, buzzer (selected by the external signal)
Power supply voltage C51 24 V d.c/a.c dual usage, 50 – 60 ㎐ (Standard specification)
C41 12 V d.c/a.c dual usage, 50 – 60 ㎐ ※”C41″Order made
Number of stacks 1 1 stack (Red)
2 2 stack (Red, Green)
3 3 stack (Red, Yellow, Green)
4 4 stack (Red, Yellow, Green, Blue)
5 5 stack (Red, Yellow, Green, Blue, White)

Download

Hanyoung Nux WMS Signal Light LED type Wall Mounted lilght-DpstarGroup
