Veris H606 Current Switch

Features

  • Adjustable trip point – versatility with four available amperage ranges
  • No tubing necessary – easier to install than differential pressure switches
  • Output status LEDs for fast set up
  • Easy placement – adjustable mounting bracket on the solid-core housing
  • Self-gripping iris on split-core housings for easy installation
Enquiry
Category:
Love0

Veris Industries is an energy and environmental sensor partner that provides quality products for commercial HVAC and other automation applications. We offer complete lines of reliable, long-lasting innovative power monitoring products.

Hawkeye x06 series split-core current switches provide accurate, reliable, and maintenance-free fan and pump status indication where an NC output is needed.

Dimensional Drawing

Detects Belt Loss/Coupling Shear

Now you can easily detect when drive belts slip, break, or pump couplings shear. In fact, a typical HVAC motor that loses its load has a reduction of the current draw of up to 50%. That’s why our sensors are the industry standard for status.

Monitoring Fan/Pump Motors For Positive Proof Of Flow

Applications

  • Monitoring fans, pumps, motors, and other electrical loads for proper operation
  • Detecting belt loss and motor failure…ideal for fan and pump status
  • Verifying lighting circuit loads
  • Monitoring critical motors (compressor, fuel, etc.)
  • Monitoring industrial process equipment status (OEM)

Specification

Model  H606
Application Building Automation Systems
Current Measurement Range 1.25 – 50 A
Current Sensor type Current Switch, AC
Electrical Wiring Size 24 – 14 AWG (0.2 – 2.1 mm²)
Measurement Type AC Current
Monitored Frequency Range 50 – 60 Hz
Monitored Wire Size 0.5″ (12 mm)
Mounting Split Core
Operating Humidity 10 – 90% RH, non-condensing
Operating Temperature 5 – 140 °F (-15 – 60 °C)
Output Specifications N.C. 0.1A @ 30 VDC
Outputs Switch output
Product Certification UL | CE
Product Type Sensor
Range HX06 Series
Relay Coil Voltage None
Relay Contact Ratings None
Relay Poles/Throw None
Setpoint Adjustable
Warranty 5 years

Download

Veris-H606-Current Switch_DpstarGroup
