Stroboscopes – Lutron DT-2349

Features

Digital synthesis circuit, high stability and easy adjustment.
Range : 60 to 32,000 RPM.
Adjustment resolution : 0.1 RPM/1 RPM.
High intensity light.
DCV power supply via external AC/DC adapter or can be used the optional recharge batteries.
Setting button : digital rotate button, X 2 button, 1/2 button, + button, – button, easy to adjust the desired RPM.

Categories: Test Instruments, Lutron ~ Test Instruments, Thiết bị test, Stroboscopes

Stroboscope, Digital Synthesis, High Intensity Light
Model : DT-2349

Digital synthesis circuit, high stability and easy adjustment.
Range : 60 to 32,000 RPM.
Adjustment resolution : 0.1 RPM/1 RPM.
High intensity light.
DCV power supply via external AC/DC adapter or can be used the optional recharge batteries.
Setting button : digital rotate button, X 2 button, 1/2 button, + button, – button, easy to adjust the desired RPM.

Specification

Display	5 digits ( 0 to 99999 ) LCD display.
Flash adjust range	60 to 30,000 RPM/FPM. • RPM : round per minute. • FPM : flash per minute.
Resolution	• 0.1 RPM : < 1,000 RPM. • 1 RPM :≧ 1,000 RPM
Resolution	• RPM : < 1,000 RPM. • RPM :≧ 1,000 RPM
Function buttons	Digital rotate knob, • x 2 button, ÷ 2 button, • + button, – button,
Accuracy	± (0.05 % + 1d) • Spec. tested under the environment RF Field Strength less than 3 V/M & frequency less than the 30 MHz only.
Power Consumption	DC 2.4 A ( 3600 FPM )
Power Supply	AC( 100V to 240V ) to DC 9V ( 3A ) adapter, incuded Build in battery compartment, power can be used the optional DC 1.2 V Ni-MH recharge battery ( UM-1, D size ) x 4 PCs which are not included.
Circuit	• Microcomputer LSI circuit & crystal control time base. • Digital synthesis circuit for the signal adjusting.
Signal Stability	The signal adjusting circuit is used the digital synthesis circuit, the output signal will existing high stability and not change.
Operating Temp.	0 to 50 ℃ (32 to 122 ℉).
Operating Humidity	Less than 80% R.H.
Dimension	21 x 12 x 12 cm (8.3 x 4.8 x 4.8 inch).
Weight	1Kg/2.2 LB.
Housing	Compact and impact plastic injection case with plastic mirror type reflector.
Calibration	Crystal time base and microprocessor circuit, don’t necessary take any external calibration process.
Accessories Included	• Operation manual………………………………………………1 PC. • IAC( 100V to 240V ) to DC 9V adapter ……………..1 PC.
Optional Accessory	Flash Xenon tube….Model : TBXE-2289
