Stroboscopes – Lutron DT-2299

Features

Stroboscope use high intensity LED array.
LCD display with back light.
Stroboscope range : 10 to 99,999 RPM.
External trigger for stroboscope.
Photo tach. range : 10 to 99,999 RPM.
Photo tachometer use the laser light beam.
Optional contact tach. adapter, TA-35.
Power supply : Batteries, 1.5 V (UM-1, D) x 4 PCs
AC/DC adapter is optional.

Categories: Test Instruments, Lutron ~ Test Instruments, Thiết bị test, Stroboscopes

Stroboscope, LED Array, Battery Power, + photo Tachometer, 2 in 1
Model : DT-2299

Stroboscope use high intensity LED array.
LCD display with back light.
Stroboscope range : 10 to 99,999 RPM.
External trigger for stroboscope.
Photo tach. range : 10 to 99,999 RPM.
Photo tachometer use the laser light beam.
Optional contact tach. adapter, TA-35.
Power supply : Batteries, 1.5 V (UM-1, D) x 4 PCs
AC/DC adapter is optional.

Specification

Display	5 digits ( 0 to 99999 ) LCD display.
Measurement	Stroboscope Unit : FPM ( rotation per minute ). build in external trigger input.Laser Photo Tachometer Unit : RPM ( rotation per minute ).Contact Tachometer Unit : RPM ( rotation per minute ). Surface speed ( ft/min., m/min ) • It should cooperate with optional contact probe ( TA-35 ).
Sampling Time	Approx. 1 second.
Calibration	Crystal time base and microprocessor circuit, no external calibration process required.
Operating Temperature	0 to 50 ℃ ( 32 to 122℉ )
Humidity	Less than 80% R.H.
Power Supply	DC 1.5 V, UM-1 (D type) battery x 4 PCs * DC 9V adapter input is built, AC/DC adapter is opional, not in included.
Power Consumption	• Stroboscope ( 3600 FPM ) : DC 160 mA. • Laser photo Tachometer ( 3600 RPM ) : DC 130 mA.
Circuit	Exclusive one-chip design microprocessor LSI circuit.
Dimension	21 cmx12 cmx12 cm (8.3″x4.8″x4.8″).
Weight	800 g ( 1.76 LB ).
Included Accessories	Contact Tachometer probe ( TA-35 ). ACV 110V, 220/230V to DC 9V adapter.
