Pressure Sensor – Lutron PS-100-XXBAR

Features

Pressure sensor connected with PS-9302
PS100-2BAR : 2 bar sensor.
PS100-5BAR : 5 bar sensor.
PS100-10BAR : 10 bar sensor.
PS100-20BAR : 20 bar sensor.
PS100-50BAR : 50 bar sensor.
PS100-100BAR : 100 bar sensor.
PS100-400BAR : 400 bar sensor.

Categories: Test Instruments, Lutron ~ Test Instruments, Thiết bị test, Pressure Meters

Pressure Sensor
Model : PS-100-XXBAR

Pressure sensor connected with PS-9302
PS100-2BAR : 2 bar sensor.
PS100-5BAR : 5 bar sensor.
PS100-10BAR : 10 bar sensor.
PS100-20BAR : 20 bar sensor.
PS100-50BAR : 50 bar sensor.
PS100-100BAR : 100 bar sensor.
PS100-400BAR : 400 bar sensor.

Specifications

Max capacity & Model	Max capacity	Model
	• 2 BAR ( 29 PSI ) • 5 BAR ( 72.5 PSI ) • 10 BAR ( 145 PSI ) • 20 BAR ( 290 PSI ) • 50 BAR ( 725 PSI ) • 100 BAR ( 1450 PSI ) • 200 BAR ( 2900 PSI )	PS100-2BAR PS100-5BAR PS100-10BAR PS100-20BAR PS100-50BAR PS100-100BAR PS100-400BAR
Application	Optional pressure transducer for the pressure meter PS-9302
Overload protection for the pressure sensor	150% max. capacity
Supply voltage	DC 9V
Transducer Port Connector	1/4″ PS ( per inch 19 teeth ).
Span	± 1 % F.S. • Within 10 ℃ to 40 ℃ . • Linearity + Hysteresis + Repeatability
Zero	± 2 % F.S. • Within 10 ℃ to 40 ℃ .
Operating Temperature	0 ℃ to 60 ℃ ( 32 ℉ to 140 ℉ ).
Operating Humidity	Max. 80% RH.
Output	Full capacity output = 100 mV DC
Size	30 mm dia. x 85 mm.
Weight	160 g.
Cable length	1 meter.
Wire Connection	4 pins standard DIN plug to cooperate the PS-9302 input socket. • 2 pins for 5V DC power supply. • 2 pins for 100 mV DC input signal.

Download

Lutron PS-100-XXBAR – Pressure Sensor-DpstarGroup
