Infrared Temperature Transmitter – Lutron TR-IR420

4-20 mA output, Infrared Temperature
Infrared Temperature Transmitter
Model : TR-IR420

• Analog outputs, 4 to 20 mA : 4 mA = 0 oC ( 32 oF ), 20 mA = 300 oC ( 572 oF )
• Emissivity : 0.95, fixed.
• D/S ( Distance/spot ) ratio : 7 : 1.
• Power supply : DC 9V to 30 V : Max. Output Load : 200 ohms.
• 3 wires : Red, bare wire : Power supply Black, bare wire : 4 to 20 mA output.
• Output Temp. ranges : 0 to 300 oC ( 0.053 mA/oC ), 32 to 572 oF ( 0.028 mA/oF ).
• Mounting : Tripod Fix Nut.
• Size : 160 x 92 x 45 mm.
