Explosion Proof Smartphones – Ecom Smart-Ex 01M

Features

  • 4G / LTE -standard (SIM unlocked and free)
  • Android 4.4, operating system
  • 4.0“ capacitive multi-touch screen made of extreme shock and scratch resistant Gorilla® Glass 2
  • Glove Touch Screen
  • High Visibility Display in Direct Sunlight
  • NFC functionality
  • 3600 mAh Li-Ion battery pack
  • Bluetooth 4.0 incl. BLE (Bluetooth Low Energy) BLE (30 times faster, 1/100th of power)
  • WIFI 802.11 a/b/g/n
  • (Optional) 8 MP rear camera with auto focus and LED flash with torchlight function and 1 MP front camera
  • 5-pins water-proof magnetic USB 2.0 High Speed connector
  • IP68 – Dust proof, water proof
  • Push-to-talk (App solution)
  • Dedicated Hardware buttons for PTT, LWP functions
  • (Optional) Lone Worker Protection (App solution)
  • (Optional) Service Level Agreemeent (SLA)
Enquiry
Categories: , , ,
Love0

The Smart-Ex 01M comes with the same and unrivalled features as the Zone 1 / Division 1 Smartphone, the Smart-Ex 01: Same performances, same features, same quality. Of course, it is also unlocked, can be used with dirty or wet work gloves and has a powerful battery for a long workday.

However, it is important to know that the Smart-Ex 01M is a stand-alone device with an own mining certification. Therefore and because of certification reasons a yellow leather case is required in underground mining locations. The Smart-Ex 01M with an ambient temperature range from 0°C to +50°C is approved and certified for use in ATEX and IECEx Mining areas.

Specification

Operating System Android 4.4, Operating System
Processor Firmware Over-the-Air (FOTA)
Chipset MSM8926 1.2 GHz Quad core
Band Cellular frequency bands EU variant:
• 4G LTE: B1, B3, B7, B8, B20, B38
• 3G UMTS: 850 / 900 / 1900 / 2100 MHz
• 2G GSM: 850 / 900 / 1800 / 1900 MHzCellular frequency bands US variant:
• 4G LTE: B1, B2, B3, B4, B5, B7, B8, B12,
• 3G UMTS: 850 / 900 / 1900 / 2100 MHz
• 2G GSM: 850 / 900 / 1800 / 1900 MHz
Memory 16GB Internal Storage / 1GB RAM 12GB user memory
Display 4.0 inch WVGA (480×800) & Corning® Gorilla® Glass 2 with Glove Touch, Blanview-Display
Ports 3.5 mm audio connector / Magnetic USB connector plug
Dimensions 163 x 82 x 22 mm
Weight approx. 370 g (13.05 oz)
Dedicated Keys PTT key / Alarm key / Power key
Connectivit •  4G / LTE -standard
•  MIMO antenna for LTE
•  WiFi 802.11 a/b/g/n dual-band, WiFi Direct, WiFi Hotspot
•  BT® 4.0 / BLE (Bluetooth® Low Energy) Support SMS and MMS (Bluetooth®, SMS, MMS (text, image, audio, video))
•  A-GPS, GLONASS, NFC
Camera 8 MP auto focus rear, 1 MP fixed focus front
Capacity (mAh) 3600 mAh
Battery Up to 1000 hours Stand by, up to 40 hours talk time
Protection class IP68
Supported Language • Arabic •Simplified •Chinese •Croatian •Czech •Danish •Dutch •English •Finnish •French •German •Greek •Hungarian •Italian •Norwegian •Persian •Polish •Portuguese •Romanian •Russian •Spanish •Swedish •Turkish
Email Client EAS, Gmail, POP 3, IMAP
Ambient temperature • 0°C … +50°C
Size 137mm x 72,1mm x 26,9mm (5.39″ x 2.84″ x 1.06″)
Certifications FCC , PTCRB , IEEE1725, CEC, Bluetooth® SIG, WFA , IC
Colors 16.7 M
Outdoor Visibility Yes
Microphone Dual Mic Solution with Noise cancellation
Speaker 19 mm Loud Speaker with Gore® Protective Vents, Output up to 103 dB
Audio Formats MP3, WMA 9, AAC , ACC +, eAAC +, AMR-NB/WB
Video Formats Support AV I, MP4, 3GPP
Media Player Android™ native + GMS
FM Radio Yes
LED torch light Yes
