Anemometer Adapter – Lutron AM-402

Features

Measurement : m/s, km/h, ft/min, knots.
Output : 1 mV per 1 m/s, per 1 km/h, per 100 ft/min, per 1 knots.
Size : 100x50x25 mm, Sensor-72 mm Dia.

Categories: Test Instruments, Lutron ~ Test Instruments, Adapters For DMMs & Clamps, Thiết bị test, DMM, Mulitimeter

Anemometer Adapter
Model : AM-402

Measurement : m/s, km/h, ft/min, knots.
Output : 1 mV per 1 m/s, per 1 km/h, per 100 ft/min, per 1 knots.
Size : 100x50x25 mm, Sensor-72 mm Dia.

Specification

Range	• 0.4 – 30.0 m/s, • 1.4 – 108.0 km/h, • 80 – 5910 ft/min, • 0.8 – 58.3 knots.
Output	• m/s – 1 mV per 1 m/s. • km/h – 1 mV per 1 km/h. • ft/min – 1 mV per 100 ft/min. • knots – 1 mV per 1 knots.
Accuracy 25 m/s)	• m/s – ± (2% + 0.1 mV) • km/h – ± (2% + 0.3 mV) • ft/min – ± (2% + 0.2 mV) • knots – ± (2% + 0.2 mV)
Sensor	Conventional twisted vane arms &
Structure	low friction ball bearing design.
Battery	006P DC 9V battery ( heavy duty type ).
Power Failure	Build in low battery indicator.
Operating Temp.	0 to 50 °C (32 to 122 ).°F
Operating Humidity	Less than 80% RH.
Dimension	• Main instrument :100 x 50 x 25 mm ( 3.9 x 2.0 x 1.0 inch ). • Sensor Head : Round, 72 mm Dia.
Standard Accessories	• Instruction Manual …………………………………… 1 PC • Sensor probe………………………………………….. 1 PC.

Download

Lutron AM-402 Anemometer adapter-DpstarGroup
