4 Tones Melody Buzzer – Hanyoung HY-606MD / HY-606MA

Features

  • 4 tones of melody selectable
  • Compact, lightweight, high capacity tones
  • Low power consumption and long life expectancy
  • Simple installation structure due to the panel installation type
Enquiry
Category:

HY-606MD / HY-606MA

  • 4 tones of melody selectable
  • Compact, light weight, high capacity tones
  • Low power consumption and long life expectancy
  • Simple installation structure due to the panel installation type

Specification

Model HY-606 MD, MA
Decibel 98 dB Max.
Power supply voltage 12, 24 V DC (HY-606MD) / 110, 220 V AC (HY-606MA)
Power frequency 50/60 ㎐ (Dual usage) – (HY-606MA)
Power consumption Approx 2.5 W
Installation hole Ø66 panel cutout
Tone types H1 Fire
H2 Ambulance
H3 Police
H4 Music (For Elise)

Ordering Code

Model Code Description
HY-606 4 tones melody buzzer
Power supply voltage MD 12 / 24 V d.c
MA 110 – 220 V a.c
