3 Tones Electronic Buzzer – Hanyoung HY-226M / HY-256M

Features

Compact, lightweight, and composed of 3 melodies
Front LED lighted when operating the buzzer
Excellent attachment due to the panel type
Low power consumption

Category: Buzzer

HY-226M / HY-256M

Compact, lightweight, and composed of 3 melodies
Front LED lighted when operating the buzzer
Excellent attachment due to the panel type
Low power consumption

Specification

Model	HY-226 MD	HY-226 MA	HY-256 MD	HY-256 MA
Installation Diameter	Ø22 / Ø25 dual usage		Ø25
Power Supply Voltage	12 – 24 V d.c	100 – 240 V a.c (50 – 60 Hz)	12 – 24 V d.c	100 – 240 V a.c (50 – 60 Hz)
Power Consumption	0.6 W	13.5 W	0.6 W	13.5 W
Volume	80 dB	80 dB	80 dB	80 dB

Ordering Code

Model	Code		Description
HY –			3 tones electronic buzzer
Dimension	226		Ø22 / Ø25 dual usage (Rectangular shaped front)
Dimension	256		For Ø25 installation (Round shaped front)
Power Supply Voltage		MD	12 – 24 V d.c
Power Supply Voltage		MA	100 – 240 V a.c

Download

Hanyoung HY-226M / HY-256M – 3 Tones Electronic Buzzer-DpstarGroup
